OUTBOARDS
BFT250D
HIGH POWER
Looking for super power? Our largest, highest horsepower four stroke outboard, the BFT250D, brings a large displacement 3.6 liter V6. This narrow v6 design offers top performance and durability, as well as great fuel economy. The high output alternator provides a 90 amp alternator with 60 charging amps.
The new BFT250D provides a broader torque range and smoother power throughout the engine’s operating range. With an innovated exterior, the improvement of corrosion resistance and water intrusion makes BFT250D the right choice.
Tohatsu 250 hp 4-Stroke Benefits
- High output alternator that produces 90 amp alternator with 60 charging amps
- Large Displacement 3.6 Litre V6
- Available in 25" shaft lengths. Standard and Counter rotation
- Double sealed multi-layered paint process to help protect against corrosion
- Semi direct air intake system
- Enhanced sealing system by adopting three new large locks
4-Stroke Technology
- Lean burn control for better fuel economy at cruising speeds
- Maximum Acceleration System helps to deliver an exceptional hole shot
- Variable valve timing and lift control
- 3-Way Cooling System to help protect against overheating
- Heavy duty 5" diameter gear case built to withstand extreme conditions
- Non-linear rubber mounts provide smoother operation at all engine speeds
- A crankshaft-driven trochoid oil pump ensures long-term durability of critical engine components
- Optimized Fuel Injection delivers the precise amount of fuel/air to each cylinder
Fundamentals for User Convenience and Reliability
- Through the prop exhaust for a quieter ride
- Built-in freshwater flushing system for easy routine flushing
- Separate dual air intake cowling design to help keep your engine's critical components cool
- Sealed starter motor that is inverted into a sealed chamber to help protect vital components against elements
- Electronic Control Module protocols allow engine data to be interfaced with on-board systems and systems displays, such as SONAR or GPS
Warning & Protection
- Low oil pressure warning
- Overheat warning
- Low battery voltage warning
- Water in fuel warning
- Start-in-gear protection
- Over-rev. limiter
SPECIFICATIONS
| Engine (No. of Cylinder) | 6 Cylinder SOHC, 60 degrees V6, 24 Valve |
|---|---|
| Output | 250 ps (186.4 kw) |
| Displacement | 3,583 cc (218.6 cu.in.) |
| Bore x Stroke | 89 x 96 mm (3.5 x 3.8 in) |
| Max. RPM Range | 5,300 - 6,300 |
| Starting | Electric |
| Control Type | Remote Control |
| Gear Shift | Forward - Neutral - Reverse |
| Gear Ratio | 2.0:1 (12:24) |
| Ignition System | MicroComputer Programmed |
| Propeller Selection Range | 15" - 27" |
| Transom Height | 25" |
| Fuel | Unleaded Gasoline (87 Octane) or higher |
| Oil Type | NMMA Certified FC-W® 4-stroke oil** SAE 10W-30 (SF, SG, SH, SJ) |
| Oil Capacity | 7.8L (2.1 US Gal.) w/filter |
| Weight* | 284 kg (626 lbs.) |
| Alternator Output | 12V, 1080W, 90A |
| Programmed Fuel Injection | Standard |
| Start In Gear Protection | Standard |
| Thermostat Controlled Cooling System | Standard |
| Through-The-Prop Exhaust | Standard |
| Overheat Buzzer | Standard |
| Oil Pressure Warning | Standard |
| Power Trim and Tilt | Standard |
| Variable Valve Timing & Lift Control | Standard |
* Weight specification is based on the lightest version.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.
| Model | Shaft Length | Cylinders | Electric Start | Remote Control | 12V Charging System |
Power Trim &Tilt |
Counter Rotation |
|---|---|---|---|---|---|---|---|
| BFT250DXRU | 25" | 6 | S | S | S | S | |
| BFT250DXCRU | 25" | 6 | S | S | S | S | S |
S:Starndard
- Specifications subject to change without notice. Additional models and/or configurations may be available. Contact your local dealer for details.
